BCC is an open standard, non spray blind mate quick coupling developed for liquid cooling of optical modules. Specifically designed for LPO optical modules, its patented design meets the thermal management requirements of LPO applications. Large radial and axial misalignment tolerance ensures convenient and reliable blind mate connection, enabling tool free optical module replacement during operation and maintenance.
| Nominal Diameter | DN01 |
| Working Pressure | 0-6bar |
| Misalignment Data | X/Y ±0.3mm, Z±0.8mm |
| Body Material | SS 303, Passivation |
| Working Temperature | 5°C ~ 70°C |
| Seal Material | FVMQ |
| Fluids | Ethylene glycol coolant, propylene glycol cool-ant, deionized water, etc |
| Product Features | No‑drip, compact size (max. outer diameter 5 mm), ultra‑low insertion force |
Zero Leakage
Hot disconnect at 6.9 bar
5,000 safe mating cycles
Low Flow Resistance
