XBMC is a global quick coupling standard developed under the XPO specification for open standard, non drip liquid cooling of optical modules. As an open standard, it enables interoperability among products from different manufacturers that comply with the XBMC specification. Netonx XBMC quick coupling series is designed to comply with or exceed the applicable standard requirements.
| Nominal Diameter | DN02 |
| Working Pressure | 0-7bar |
| Misalignment Data | X/Y ±0.5mm, Z－0.5mm |
| Body Material | SS 303, Passivation |
| Working Temperature | 17°C ~ 65°C |
| Seal Material | EPDM(HNBR、 FVMQ optional) |
| Fluids | Ethylene glycol coolant, propylene glycol cool-ant, deionized water, etc |
| Product Features | No‑drip when connecting and disconnecting |
Zero Leakage
Hot disconnect at 6.9 bar
5,000 safe mating cycles
Low Flow Resistance
